TPR Westflex™ 4 in 1 RGBW Tapelight V2

Choose the appropriate IES file below:
Product Description:
The TPR Westflex™ 4-in-1 RGBW Tapelight V2 is a solid state tape light for Architectural and Entertainment markets. It is flexible, cuts to length every 4” and uses a high brightness 5050 LED for maximum performance. It is available in indoor or outdoor (IP67) jackets, and is fully controllable via DMX512 when used in conjunction with the Westpower™ 300-4 data box. The White quadrant of the LED chip is available in 3200K and 4200K.
Specifications:
Lumens: 475 lm/ft (at full RGBW)
Power: 7.4W/ft
Operating Voltage: 24VDC
Operating Temp: -4F to 104F (-20C to 40C)
Dimensions:
12mm W (without weatherproof jacket) x 3mm H
14mm W (with weatherproof jacket) x 4mm H
Power: 7.4W/ft
Operating Voltage: 24VDC
Operating Temp: -4F to 104F (-20C to 40C)
Dimensions:
12mm W (without weatherproof jacket) x 3mm H
14mm W (with weatherproof jacket) x 4mm H
Max Run: 16.4' on Single Power Feed
Lamp Life: 50,000hrs @70% lumen maintenance
Max Lead: 35' with AWG18
Viewing Angle: 120 Degrees
Cut Length: 3.937" (100mm)
LEDs per Ft: 18
PC Board: 12mm
Lamp Life: 50,000hrs @70% lumen maintenance
Max Lead: 35' with AWG18
Viewing Angle: 120 Degrees
Cut Length: 3.937" (100mm)
LEDs per Ft: 18
PC Board: 12mm
Certifications:

Ordering Logic:
Model
TPR-FL-SMD
Model
—
Model
RGBW4V2
Model
—
CCT
2700K
3000K
4000K
6500K
Model
—
Protection (P) Rating
NP (no jacket)
IP (indoor protected)
WP (weather protected)
